GRP4: Group 4

The GRP4 module contains six different samplers that can be sequenced with SEQ4. Right-click a sampler to make it follow another trigger. See also Trigger Source. Select the sampler to edit with the tabs 1 to 6 on the left. The small buttons beside the tabs play each sampler once.

Parameter	Description
N (Activator Switch)	Turns the module on or off. The N key does the same by default.
PRESET	Stores and recalls the settings of all six samplers. See also Preset Selector.
MUTE GRP	When on, an instrument that plays cuts off the others in this group that share a BUS1-BUS3 or FX1-FX3 output. See also Mute.
GROUP GAIN	The number box at the lower left. Sets the level of all six samplers together, from silence (-inf dB) to 0 dB.

---

4-1 : Sampler

Parameter	Description
FILE MENU	Selects the sound file. See also Sound File Menu.
CV	Chance that the trigger reaches the FX, the sends, the mixer, and the trigger outputs. See also Trigger Events (CV).
BUS	Where the sound goes, in any combination. SEND enables the DL1, DL2, and RVB dials. See also Audio Bus.
ENVELOPE	Sets the volume and pitch envelopes. See also Envelope.
PCH	Tunes the sound smoothly, up to 3 octaves up or down (1.00 = original pitch).
TRP	Transposes the sound in semitones, from -36 to +36. Adds to PCH and to the TRP module.
REV	Sets the chance that a hit plays in reverse.
VOICE	Sets how many hits can sound at once, from 1 to 8. A new hit beyond that cuts off the oldest.
LFO MENU	Shows the LFO’s shape and targets. Click to open the LFO panel. Targets: PCH, DRV, PHAS, FRQ, BIT, SMP, HPF, LPF, RES, DL1, DL2, RVB, PAN, LEV. See also LFO.
DRV	Randomizable Adjusts the amount of overdrive.
PHAS	Randomizable Adjusts the amount of phaser.
FRQ	Randomizable Adjusts the frequency of phaser.
LFO	Randomizable Adjusts the frequency of the LFO.
AMT	Randomizable Adjusts the amount of LFO modulation.
BIT	Randomizable Adjusts the bit depth. Lower values produce a lo-fi sound.
SMP	Randomizable Adjusts the sample rate.
HPF	Randomizable Adjusts the cutoff frequency of the high-pass filter.
LPF	Randomizable Adjusts the cutoff frequency of the low-pass filter.
RES	Randomizable Adjusts the resonance amount of the high-pass and low-pass filter.
DL1	Randomizable Adjusts the send level to DL1.
DL2	Randomizable Adjusts the send level to DL2.
RVB	Randomizable Adjusts the send level to RVB.
PAN	Randomizable Adjusts the panning.
LEV	Randomizable Adjusts the output level.

---

4-2 : Slice Sampler

Each hit plays the next slice in the order DIRECTION sets, and the step moves on by one slice per hit. Set DIV above 1 to cut the file into slices.

Parameter	Description
FILE MENU	Selects the sound file. See also Sound File Menu.
CV	Chance that the trigger reaches the FX, the sends, the mixer, and the trigger outputs. See also Trigger Events (CV).
BUS	Where the sound goes, in any combination. SEND enables the DL1, DL2, and RVB dials. See also Audio Bus.
DIV	Sets the number of slices, from 1 to 128. At 1 (the default) the whole file plays as one slice.
SLICE DISPLAY	Shows the waveform of the file, the slice lines, and the slice now playing.
DIRECTION	Chooses the order the slices play in: forward, backward, or back and forth.
RND	Sets the chance that a hit jumps to a random slice instead of the next one.
REV	Sets the chance that a hit plays in reverse.
QTZ	When on, each slice is sped up or slowed down, pitch included, so its length snaps to the nearest note length (1/64, 1/32, …) at the current BPM.
ENVELOPE MENU	Selects the volume shape of each slice: FLAT, LINEAR, PLUCK, or DUCK.
LFO MENU	Shows the LFO’s shape and targets. Click to open the LFO panel. Targets: DRV, PCH, SMP, HPF, LPF, RES, DL1, DL2, RVB, PAN, LEV. See also LFO.
LFO	Adjusts the frequency of the LFO.
AMT	Adjusts the amount of LFO modulation.
DRV	Adjusts the amount of overdrive.
PCH	Randomizable Tunes the sound smoothly, up to 3 octaves up or down (1.00 = original pitch).
SMP	Randomizable Adjusts the sample rate.
HPF	Randomizable Adjusts the cutoff frequency of the high-pass filter.
LPF	Randomizable Adjusts the cutoff frequency of the low-pass filter.
RES	Randomizable Adjusts the resonance amount of the high-pass and low-pass filter.
DL1	Randomizable Adjusts the send level to DL1.
DL2	Randomizable Adjusts the send level to DL2.
RVB	Randomizable Adjusts the send level to RVB.
PAN	Randomizable Adjusts the panning.
LEV	Randomizable Adjusts the output level.

---

4-3 : Granular Sampler

Parameter	Description
FILE MENU	Selects the sound file. See also Sound File Menu.
CV	Chance that the trigger reaches the FX, the sends, the mixer, and the trigger outputs. See also Trigger Events (CV).
BUS	Where the sound goes, in any combination. SEND enables the DL1, DL2, and RVB dials. See also Audio Bus.
LEN	Sets how long one hit lasts, in sixteenth notes, from 1/4 to 64, so it follows the tempo. The envelopes are drawn across this length.
ENVELOPE SELECTOR	Chooses the envelope the editor shows: POS (position), SIZE (grain size), DIST (grain distance), JIT (jitter), AMP, or PCH.
CLEAR	Resets every envelope to its default shape.
ENVELOPE	Draws the selected envelope. See also Envelope.
PCH	Randomizable Tunes the sound smoothly, up to 4 octaves up or down (0 = original pitch).
SMP	Randomizable Adjusts the sample rate.
HPF	Randomizable Adjusts the cutoff frequency of the high-pass filter.
LPF	Randomizable Adjusts the cutoff frequency of the low-pass filter.
RES	Randomizable Adjusts the resonance amount of the high-pass and low-pass filter.
DL1	Randomizable Adjusts the send level to DL1.
DL2	Randomizable Adjusts the send level to DL2.
RVB	Randomizable Adjusts the send level to RVB.
PAN	Randomizable Adjusts the panning.
LEV	Randomizable Adjusts the output level.

---

4-4 : Sampler

The controls are the same as 4-1.

---

4-5 : Slice Sampler

The controls are the same as 4-2.

---

4-6 : Granular Sampler

The controls are the same as 4-3.

---
