Modules Guide - GRP1
The GRP1 module contains three samplers that can be sequenced with SEQ1.
| Parameter | Description |
|---|---|
| MUTE GRP | Turns the mute on or off. See also Mute. |
1-1 : Sampler with Kick Synth
| Parameter | Description |
|---|---|
| Z (Activator Switch) | Turns the module on or off, also operated by pressing the Z key. |
| FILE MENU | Selects the sound file. See also Sound File Menu. |
| CV | Sets the probability of sending CV. See also Trigger Events (CV). |
| BUS | Selects the output destination for the module. See also Audio Bus. |
| ENVELOPE | Sets the volume and pitch envelopes. See also Envelope. |
| PCH | Adjusts the pitch of the sound. |
| TRP | Adjusts the pitch of the sound in semitone steps. |
| REV | Sets the probability of reverse playback. |
| VOICE | Sets the maximum number of voices that can play at once. |
| LFO MENU | Selects the LFO waveform and target. |
| DRV | Randomizable Adjusts the amount of overdrive. |
| RM | Randomizable Adjusts the amount of ring modulation. |
| FRQ | Randomizable Adjusts the frequency of ring modulation. |
| HPF | Randomizable Adjusts the cutoff frequency of the high-pass filter. |
| LPF | Randomizable Adjusts the cutoff frequency of the low-pass filter. |
| RES | Randomizable Adjusts the resonance amount of the high-pass and low-pass filter. |
| LFO | Randomizable Adjusts the frequency of the LFO. |
| AMT | Randomizable Adjusts the amount of LFO modulation. |
| BIT | Randomizable Adjusts the bit depth. Lower values produce a lo-fi sound. |
| SMP | Randomizable Adjusts the sample rate. |
| OVT | Randomizable Adjusts the amount of overtone. |
| DL1 | Randomizable Adjusts the send level to DL1, which is not sent if the send bus is disabled. |
| DL2 | Randomizable Adjusts the send level to DL2, which is not sent if the send bus is disabled. |
| RVB | Randomizable Adjusts the send level to RVB, which is not sent if the send bus is disabled. |
| PAN | Randomizable Adjusts the panning. |
| LEV | Randomizable Adjusts the output level. |
| KICK ENVELOPE | Sets the volume and pitch envelopes of the kick synth. See also Envelope. |
| LEN | Adjusts the length of the kick synth. |
| FRQ | Adjusts the frequency of the kick synth. |
| CLK | Randomizable Adjusts the noise level of the kick synth. |
| TONE | Randomizable Adjusts the kick tone. |
| KCK | Randomizable Adjusts the output level of the kick synth. |
| KCK TRIG | Selects the trigger condition for the kick synth. |
| KCK OUT | Selects the output destination for the kick synth. |
1-2 : Sampler
| Parameter | Description |
|---|---|
| X (Activator Switch) | Turns the module on or off, also operated by pressing the X key. |
| FILE MENU | Selects the sound file. See also Sound File Menu. |
| CV | Sets the probability of sending CV. See also Trigger Events (CV). |
| BUS | Selects the output destination for the module. See also Audio Bus. |
| ENVELOPE | Sets the volume and pitch envelopes. See also Envelope. |
| PCH | Adjusts the pitch of the sound. |
| TRP | Adjusts the pitch of the sound in semitone steps. |
| REV | Sets the probability of reverse playback. |
| VOICE | Sets the maximum number of voices that can play at once. |
| LFO MENU | Selects the LFO waveform and target. |
| DRV | Randomizable Adjusts the amount of overdrive. |
| RM | Randomizable Adjusts the amount of ring modulation. |
| FRQ | Randomizable Adjusts the frequency of ring modulation. |
| HPF | Randomizable Adjusts the cutoff frequency of the high-pass filter. |
| LPF | Randomizable Adjusts the cutoff frequency of the low-pass filter. |
| RES | Randomizable Adjusts the resonance amount of the high-pass and low-pass filter. |
| LFO | Randomizable Adjusts the frequency of the LFO. |
| AMT | Randomizable Adjusts the amount of LFO modulation. |
| BIT | Randomizable Adjusts the bit depth. Lower values produce a lo-fi sound. |
| SMP | Randomizable Adjusts the sample rate. |
| OVT | Randomizable Adjusts the amount of overtone. |
| DL1 | Randomizable Adjusts the send level to DL1, which is not sent if the send bus is disabled. |
| DL2 | Randomizable Adjusts the send level to DL2, which is not sent if the send bus is disabled. |
| RVB | Randomizable Adjusts the send level to RVB, which is not sent if the send bus is disabled. |
| PAN | Randomizable Adjusts the panning. |
| LEV | Randomizable Adjusts the output level. |
1-3 : Sampler
| Parameter | Description |
|---|---|
| X (Activator Switch) | Turns the module on or off, also operated by pressing the X key. |
| FILE MENU | Selects the sound file. See also Sound File Menu. |
| CV | Sets the probability of sending CV. See also Trigger Events (CV). |
| BUS | Selects the output destination for the module. See also Audio Bus. |
| ENVELOPE | Sets the volume and pitch envelopes. See also Envelope. |
| PCH | Adjusts the pitch of the sound. |
| TRP | Adjusts the pitch of the sound in semitone steps. |
| REV | Sets the probability of reverse playback. |
| BIT | Randomizable Adjusts the bit depth. Lower values produce a lo-fi sound. |
| SMP | Randomizable Adjusts the sample rate. |
| OVT | Randomizable Adjusts the amount of overtone. |
| DL1 | Randomizable Adjusts the send level to DL1, which is not sent if the send bus is disabled. |
| DL2 | Randomizable Adjusts the send level to DL2, which is not sent if the send bus is disabled. |
| RVB | Randomizable Adjusts the send level to RVB, which is not sent if the send bus is disabled. |
| PAN | Randomizable Adjusts the panning. |
| LEV | Randomizable Adjusts the output level. |
Controllable Parameters (323 Parameters)
| Category | OSC address | Range | Default |
|---|---|---|---|
| PRESET | /group1/preset/{KEY(A-K)} | PRESET - | - |
| PRESET | /group1/preset/{KEY(Q-P)} | PRESET - | - |
| TRIG | /group1/1/trigger | TRIGGER 0.00 - 1.00 | - |
| PARAM | /group1/1/enable | TOGGLE ON - OFF | ON |
| PARAM | /group1/1/bitcrush | NUMBER 0 - 127 | 127 |
| PARAM | /group1/1/bitcrush/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/bitcrush/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/bus/bus1 | TOGGLE ON - OFF | ON |
| PARAM | /group1/1/bus/bus2 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/bus/bus3 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/bus/fx1 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/bus/fx2 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/bus/fx3 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/bus/send | TOGGLE ON - OFF | ON |
| PARAM | /group1/1/bus/send/delay1 | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/bus/send/delay1/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/bus/send/delay1/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/bus/send/delay2 | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/bus/send/delay2/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/bus/send/delay2/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/bus/send/reverb | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/bus/send/reverb/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/bus/send/reverb/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/cv | NUMBER 0% - 100% | 100% |
| PARAM | /group1/1/dejavu/length | NUMBER 1 - 32 | 8 |
| PARAM | /group1/1/dejavu/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/downsample | NUMBER 0 - 127 | 127 |
| PARAM | /group1/1/downsample/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/downsample/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/envelope/amp/{POINT(1-4)}/curve | NUMBER 0.33 - 3.00 | 1.00 |
| PARAM | /group1/1/envelope/amp/{POINT(1-4)}/range/x | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/envelope/amp/{POINT(1-4)}/range/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/envelope/amp/{POINT(1-4)}/x | NUMBER 0.00 - 1.00 | 1.00 |
| PARAM | /group1/1/envelope/amp/{POINT(1-4)}/y | NUMBER 0.00 - 1.00 | 0.50 |
| PARAM | /group1/1/envelope/pitch/{POINT(1-3)}/curve | NUMBER 0.33 - 3.00 | 1.00 |
| PARAM | /group1/1/envelope/pitch/{POINT(1-3)}/range/x | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/envelope/pitch/{POINT(1-3)}/range/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/envelope/pitch/{POINT(1-3)}/x | NUMBER 0.00 - 1.00 | 1.00 |
| PARAM | /group1/1/envelope/pitch/{POINT(1-3)}/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/filter/highpass | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/filter/highpass/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/filter/highpass/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/filter/lowpass | NUMBER 0 - 127 | 127 |
| PARAM | /group1/1/filter/lowpass/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/filter/lowpass/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/filter/resonance | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/filter/resonance/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/filter/resonance/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/kick | NUMBER 0 - 127 | 64 |
| PARAM | /group1/1/kick/trigger | CHOICES NONE, ALL, ACCENT | ALL |
| PARAM | /group1/1/kick/trigger/accent | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/kick/trigger/all | TOGGLE ON - OFF | ON |
| PARAM | /group1/1/kick/trigger/none | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/kick/click | NUMBER 0 - 127 | 64 |
| PARAM | /group1/1/kick/click/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/kick/click/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/kick/envelope/amp/{POINT(1-3)}/curve | NUMBER 0.33 - 3.00 | 1.00 |
| PARAM | /group1/1/kick/envelope/amp/{POINT(1-3)}/range/x | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/kick/envelope/amp/{POINT(1-3)}/range/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/kick/envelope/amp/{POINT(1-3)}/x | NUMBER 0.00 - 1.00 | 1.00 |
| PARAM | /group1/1/kick/envelope/amp/{POINT(1-3)}/y | NUMBER 0.00 - 1.00 | 0.50 |
| PARAM | /group1/1/kick/envelope/pitch/{POINT(1-2)}/curve | NUMBER 0.33 - 3.00 | 0.33 |
| PARAM | /group1/1/kick/envelope/pitch/{POINT(1-2)}/range/x | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/kick/envelope/pitch/{POINT(1-2)}/range/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/1/kick/envelope/pitch/{POINT(1-2)}/x | NUMBER 0.00 - 1.00 | 0.20 |
| PARAM | /group1/1/kick/envelope/pitch/{POINT(1-2)}/y | NUMBER 0.00 - 1.00 | 0.30 |
| PARAM | /group1/1/kick/frequency | NUMBER 20.0Hz - 3.0kHz | 40.0Hz |
| PARAM | /group1/1/kick/length | NUMBER 0.12 - 32.00 | 2.00 |
| PARAM | /group1/1/kick/out | CHOICES PRE, POST, BUS1 | PRE |
| PARAM | /group1/1/kick/out/bus1 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/kick/out/post | TOGGLE ON - OFF | OFF |
| PARAM | /group1/1/kick/out/pre | TOGGLE ON - OFF | ON |
| PARAM | /group1/1/kick/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/kick/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/kick/tone | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/kick/tone/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/kick/tone/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/level | NUMBER 0 - 127 | 64 |
| PARAM | /group1/1/level/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/level/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/lfo/amount | NUMBER -64 - 64 | 0 |
| PARAM | /group1/1/lfo/amount/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/lfo/amount/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/lfo/frequency | NUMBER -64 - 64 | 0 |
| PARAM | /group1/1/lfo/frequency/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/lfo/frequency/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/lfo/target | CHOICES PCH, DRV, RM, FRQ, HPF, LPF, RES, BIT, SMP, OVT, DL1, DL2, RVB, PAN, LEV, KICK LEN, KICK FRQ, KICK CLK, KICK TONE, KICK | HPF |
| PARAM | /group1/1/lfo/waveform | CHOICES SIN, SIN-UP, SIN-DOWN, TRI, TRI-UP, TRI-DOWN, SAW-UP, SAW-DOWN, SQR-UP, SQR-DOWN, RMP-UP, RMP-DOWN, RND | SIN |
| PARAM | /group1/1/overdrive | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/overdrive/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/overdrive/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/overtone | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/overtone/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/overtone/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/pan | NUMBER L50 - R50 | C |
| PARAM | /group1/1/pan/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/pan/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/pitch | NUMBER 0.12 - 8.00 | 1.00 |
| PARAM | /group1/1/reverse | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/ringmod/amount | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/ringmod/amount/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/ringmod/amount/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/ringmod/frequency | NUMBER 0 - 127 | 0 |
| PARAM | /group1/1/ringmod/frequency/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/ringmod/frequency/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/1/transpose | NUMBER -36 - 36 | 0 |
| PARAM | /group1/1/voice | NUMBER 1 - 8 | 8 |
| TRIG | /group1/2/trigger | TRIGGER 0.00 - 1.00 | - |
| PARAM | /group1/2/enable | TOGGLE ON - OFF | ON |
| PARAM | /group1/2/bitcrush | NUMBER 0 - 127 | 127 |
| PARAM | /group1/2/bitcrush/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/bitcrush/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/bus/bus1 | TOGGLE ON - OFF | ON |
| PARAM | /group1/2/bus/bus2 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/2/bus/bus3 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/2/bus/fx1 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/2/bus/fx2 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/2/bus/fx3 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/2/bus/send | TOGGLE ON - OFF | ON |
| PARAM | /group1/2/bus/send/delay1 | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/bus/send/delay1/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/bus/send/delay1/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/bus/send/delay2 | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/bus/send/delay2/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/bus/send/delay2/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/bus/send/reverb | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/bus/send/reverb/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/bus/send/reverb/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/cv | NUMBER 0% - 100% | 100% |
| PARAM | /group1/2/dejavu/length | NUMBER 1 - 32 | 8 |
| PARAM | /group1/2/dejavu/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/downsample | NUMBER 0 - 127 | 127 |
| PARAM | /group1/2/downsample/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/downsample/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/envelope/amp/{POINT(1-4)}/curve | NUMBER 0.33 - 3.00 | 1.00 |
| PARAM | /group1/2/envelope/amp/{POINT(1-4)}/range/x | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/2/envelope/amp/{POINT(1-4)}/range/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/2/envelope/amp/{POINT(1-4)}/x | NUMBER 0.00 - 1.00 | 1.00 |
| PARAM | /group1/2/envelope/amp/{POINT(1-4)}/y | NUMBER 0.00 - 1.00 | 0.50 |
| PARAM | /group1/2/envelope/pitch/{POINT(1-3)}/curve | NUMBER 0.33 - 3.00 | 1.00 |
| PARAM | /group1/2/envelope/pitch/{POINT(1-3)}/range/x | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/2/envelope/pitch/{POINT(1-3)}/range/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/2/envelope/pitch/{POINT(1-3)}/x | NUMBER 0.00 - 1.00 | 1.00 |
| PARAM | /group1/2/envelope/pitch/{POINT(1-3)}/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/2/filter/highpass | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/filter/highpass/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/filter/highpass/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/filter/lowpass | NUMBER 0 - 127 | 127 |
| PARAM | /group1/2/filter/lowpass/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/filter/lowpass/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/filter/resonance | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/filter/resonance/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/filter/resonance/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/level | NUMBER 0 - 127 | 64 |
| PARAM | /group1/2/level/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/level/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/lfo/amount | NUMBER -64 - 64 | 0 |
| PARAM | /group1/2/lfo/amount/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/lfo/amount/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/lfo/frequency | NUMBER -64 - 64 | 0 |
| PARAM | /group1/2/lfo/frequency/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/lfo/frequency/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/lfo/target | CHOICES PCH, DRV, RM, FRQ, HPF, LPF, RES, BIT, SMP, OVT, DL1, DL2, RVB, PAN, LEV | HPF |
| PARAM | /group1/2/lfo/waveform | CHOICES SIN, SIN-UP, SIN-DOWN, TRI, TRI-UP, TRI-DOWN, SAW-UP, SAW-DOWN, SQR-UP, SQR-DOWN, RMP-UP, RMP-DOWN, RND | SIN |
| PARAM | /group1/2/overdrive | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/overdrive/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/overdrive/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/overtone | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/overtone/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/overtone/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/pan | NUMBER L50 - R50 | C |
| PARAM | /group1/2/pan/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/pan/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/pitch | NUMBER 0.12 - 8.00 | 1.00 |
| PARAM | /group1/2/reverse | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/ringmod/amount | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/ringmod/amount/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/ringmod/amount/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/ringmod/frequency | NUMBER 0 - 127 | 0 |
| PARAM | /group1/2/ringmod/frequency/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/ringmod/frequency/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/2/transpose | NUMBER -36 - 36 | 0 |
| PARAM | /group1/2/voice | NUMBER 1 - 8 | 8 |
| TRIG | /group1/3/trigger | TRIGGER 0.00 - 1.00 | - |
| PARAM | /group1/3/enable | TOGGLE ON - OFF | ON |
| PARAM | /group1/3/bitcrush | NUMBER 0 - 127 | 127 |
| PARAM | /group1/3/bitcrush/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/bitcrush/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/bus/bus1 | TOGGLE ON - OFF | ON |
| PARAM | /group1/3/bus/bus2 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/3/bus/bus3 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/3/bus/fx1 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/3/bus/fx2 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/3/bus/fx3 | TOGGLE ON - OFF | OFF |
| PARAM | /group1/3/bus/send | TOGGLE ON - OFF | ON |
| PARAM | /group1/3/bus/send/delay1 | NUMBER 0 - 127 | 0 |
| PARAM | /group1/3/bus/send/delay1/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/bus/send/delay1/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/bus/send/delay2 | NUMBER 0 - 127 | 0 |
| PARAM | /group1/3/bus/send/delay2/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/bus/send/delay2/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/bus/send/reverb | NUMBER 0 - 127 | 0 |
| PARAM | /group1/3/bus/send/reverb/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/bus/send/reverb/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/cv | NUMBER 0% - 100% | 100% |
| PARAM | /group1/3/dejavu/length | NUMBER 1 - 32 | 8 |
| PARAM | /group1/3/dejavu/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/downsample | NUMBER 0 - 127 | 127 |
| PARAM | /group1/3/downsample/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/downsample/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/envelope/amp/{POINT(1-4)}/curve | NUMBER 0.33 - 3.00 | 1.00 |
| PARAM | /group1/3/envelope/amp/{POINT(1-4)}/range/x | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/3/envelope/amp/{POINT(1-4)}/range/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/3/envelope/amp/{POINT(1-4)}/x | NUMBER 0.00 - 1.00 | 1.00 |
| PARAM | /group1/3/envelope/amp/{POINT(1-4)}/y | NUMBER 0.00 - 1.00 | 0.50 |
| PARAM | /group1/3/envelope/pitch/{POINT(1-3)}/curve | NUMBER 0.33 - 3.00 | 1.00 |
| PARAM | /group1/3/envelope/pitch/{POINT(1-3)}/range/x | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/3/envelope/pitch/{POINT(1-3)}/range/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/3/envelope/pitch/{POINT(1-3)}/x | NUMBER 0.00 - 1.00 | 1.00 |
| PARAM | /group1/3/envelope/pitch/{POINT(1-3)}/y | NUMBER 0.00 - 1.00 | 0.00 |
| PARAM | /group1/3/level | NUMBER 0 - 127 | 64 |
| PARAM | /group1/3/level/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/level/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/overtone | NUMBER 0 - 127 | 0 |
| PARAM | /group1/3/overtone/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/overtone/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/pan | NUMBER L50 - R50 | C |
| PARAM | /group1/3/pan/prob | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/pan/range | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/pitch | NUMBER 0.12 - 8.00 | 1.00 |
| PARAM | /group1/3/reverse | NUMBER 0% - 100% | 0% |
| PARAM | /group1/3/transpose | NUMBER -36 - 36 | 0 |
| PARAM | /group1/mute | TOGGLE ON - OFF | OFF |
